Aegis terminal
Windows-based interface handling guidance, section, rate, curve compensation, and boom height.
Nexus technology stack
Aegis control, Mercury RTK, and the Hydra suite are engineered to work together—delivering guidance, per nozzle control, and AI spot spraying without messy integrations.
Technology overview
Every Nexus sprayer uses the same electronics stack so upgrades and service stay consistent across amenity and agriculture.
Mercury GNSS & Mercury Net
Clean installs with multi-constellation tracking and an upgrade path to nationwide cellular RTK.
Hydra Vision
AI spot spraying for green-on-green and green-on-brown targets with synchronous boom lighting.
Hydra Flow
Per nozzle PWM and blended PWM control with diagnostics for duty cycle, flow, and alarms.
Nexus Aegis Terminal
One rugged Windows tablet managing guidance, section and rate, curve compensation, Hydra Flow, and Phoenix Glide.
Feature highlights
- Integrated AB lines, headlands, and coverage logging with Task Sync
- Automatic section and rate control with curve compensation
- Hydra Flow per nozzle PWM and blended PWM control
- Phoenix Glide boom height interface with multiple sensor sets
- Prescription map import plus hazard pop ups and reporting
Key specifications
| Display | 12 inch rugged Windows tablet, sunlight readable |
| Processor | Industrial Intel module with solid state storage |
| Environmental | -20 °C to +55 °C, IP65 enclosure |
| Connectivity | CAN, optional ISOBUS bridge, Ethernet, USB |
| Power | 9 to 36 volt input with surge protection |
Supplied with Ram mount kit, fused power loom, and pre-configured Nexus software. Remote diagnostics keep rigs running.
Nexus Mercury GNSS (RTK ready)
Multi constellation receiver with clean cabling and a software unlock to Mercury Net RTK for sub-inch accuracy.
Feature highlights
- Multi constellation tracking with auto terrain compensation
- Upgrade path from SBAS to RTK without swapping hardware
- Mercury Net subscription for nationwide cellular RTK
- Low profile roof puck or bolt-on rail mounting options
- CAN and Ethernet outputs for Aegis, steering, or data logging
Key specifications
| Constellations | GPS, GLONASS, Galileo, BeiDou |
| Accuracy | 1-2 cm with Mercury Net RTK, 10 cm with SBAS |
| Corrections | RTK, SBAS, RTX bridge optional |
| Outputs | CAN, NMEA over Ethernet, optional RS232 |
| Mounting | Magnetic roof puck and bolt-on rail plate included |
Includes two metre power and data loom plus roof mounting hardware. Quick disconnect harness makes swaps easy.
Nexus Hydra Vision
AI-driven spot spraying with stabilised lighting and tight integration to Aegis and Hydra Flow for per nozzle actuation.
Feature highlights
- Dual camera modules with synchronised LED bars for day or night work
- Direct CAN link into Aegis and Hydra Flow for per nozzle actuation
- Green-on-green and green-on-brown neural models supplied
- Health monitoring with temperature, cleanliness, and misfire alerts
- Modular 3-6 metre bars expanding to 36 metre Phoenix booms
Key specifications
| Camera sections | Modular 3 metre bars (two cameras plus LED array) |
| Detection | Green-on-green and green-on-brown neural models |
| Refresh | 40 frames per second processing pipeline |
| Interface | CAN to Aegis and Hydra Flow |
| Power | 24 volt DC with auto fused loom |
Bundle includes camera bars, control module, harness kit, and cleaning tools. Swaps between amenity and agriculture rigs in minutes.
Nexus Hydra Flow
Per nozzle control with PWM and blended PWM, delivering consistent coverage and rapid diagnostics through Aegis.
Feature highlights
- Per nozzle modules with chemical resistant seals
- PWM, blended PWM, and fall back sectional modes
- Automatic curve compensation for inner/outer boom balance
- Quad nozzle bodies with LED status indication
- Aegis logging of duty cycle, flow, and alarms
Key specifications
| Control modes | PWM, blended PWM, conventional section |
| Duty cycle | 10 to 100 percent adjustable per nozzle |
| Flow rating | Up to 15 litres per minute per nozzle body |
| Ingress | IP67 sealed modules and connectors |
| Harness | Plug and play drop leads with Deutsch connectors |
Supplied with trunk harness, drop leads, modules, and service spares. Designed for quick diagnostics in the field.
Integrate the full Nexus stack
Whether you need guidance, per nozzle control, AI spot spraying, or RTK upgrades, we can tailor the electronics to your fleet.
